14.4 Mr. Potato - Scaling Symmetry
There are two ways to run this example:
-
Batch
-
Manual
The Batch Run takes only two clicks:
-
Click �Example/Neural Net/ Mr.Potato -S� ;
-
Click �Batch/Run�.
The Manual Run requires a few more clicks:
Input:
Training: .\ex_trademark\image042.jpg
Search: .\ex_trademark\
Parameters
Edge Filter: (Image Processing---------------1st box)
None
Threshold Filter: (Image Processing---------------2nd box)
Light Background 192
Clean Up Filter: (Image Processing---------------3rd box)
None
NeuralNet Filter Parameters: (Neural Net Parameters)
Scaling Symmetry
Blurring = 10
Sensitivity = 20
InternalCut = 50
ExternalCut = 100000
Operation
-
Click the "Key Segment" button and select ".\ex_trademark\image042.jpg";
-
Click the "Source" button and select ".\ex_trademark\";
-
Set the Parameters as specified above;
-
Click the "Neural Net\Train" button to train the filter;
-
Click the "NeuralNet\matching\1:N (key vs Source)" button to make a search.
Results
ID Name Path Score X Y W H R
i042_s110 i042_s110.jpg C:\...\ex_trademark\ 120128 27 315 27 306 0
i042_s120 i042_s120.jpg C:\...\ex_trademark\ 121600 27 359 27 337 0
i042_s130 i042_s130.jpg C:\...\ex_trademark\ 114496 27 381 27 372 0
i042_s140 i042_s140.jpg C:\...\ex_trademark\ 102848 13 403 13 394 0
I042_S50 I042_S50.JPG C:\...\ex_trademark\ 123712 27 293 27 271 0
I042_S60 I042_S60.JPG C:\...\ex_trademark\ 416000 13 184 13 175 0
I042_S70 I042_S70.JPG C:\...\ex_trademark\ 625000 13 206 13 197 0
I042_S80 I042_S80.JPG C:\...\ex_trademark\ 126848 27 228 27 206 0
I042_S90 I042_S90.JPG C:\...\ex_trademark\ 122176 27 249 27 241 0
IMAGE038 IMAGE038.JPG C:\...\ex_trademark\ 106880 100 321 100 145 0
IMAGE042 IMAGE042.JPG C:\...\ex_trademark\ 128000000 20 421 20 400 0
The segment location is not implemented for Scaling Symmetry.
Summary
# Images = 126
# To be retrieved = 10
# Retrieved = 11
# Retrieved Correctly = 10
# Missed = 0
Hit Ratio = 10/11
